Description
This unit can be used for Charging test and discharge test of lead-acid batteries, lithium batteries and other types of batteries.
The maximum charge & discharge cycle index is 16 times, which can also be used as the aging equipment in the battery production.
The device provides two operation modes: Panel and Software. After installing the specified software, the device can be managed and operated through the computer: charge-discharge setting, data sampling, test report imports and export, test data analysis, charge-discharge curves drawing. One computer can manage multiple devices simultaneously through a switch.
Features
- Model No. : 99V 20A 1CH
- Power Supply : AC 220V±10% 50/60HZ
- Basic Function : Charge ,Discharge ,Auto-cycle, Test data analysis, Test data import & export
- Applicable Batteries : Lead-acid battery pack, Li-ion battery pack
Battery Rated Voltage : 12V-84V
Charging Functions
Charge Methods : CV & CC
Charge Current : 0.5-10A adjustable, 0.1A stepping
Charge Cut-Off Current : 0.1-5A adjustable, 0.1A stepping
Charge Voltage Range : 9V-99V, 0.1V stepping
Charge Current Accuracy : ±0.03A
Charge Voltage Accuracy : ±0.1V
Discharging Functions
Discharge Methods : CC
Discharge Current : 9V-21V – 0.5-10A adjustable
21V-99V- 0.5-20A adjustable
Discharge Cut-Off Voltage : 9V-99V, 0.1V stepping
Discharge Current Accuracy : ±0.03A
Discharge Voltage Accuracy : ±0.1V
Max. Cycle Index : 16 times
Operation Methods : Software/Panel
Battery Connection Methods : Testing cable with clamp
Communication Port : LAN
