Description
The Chassis Dynamometer is designed to test E-Motorcycles and E-Scooters. It is specifically designed to serve as a load unit with energy consumption testing, distance accumulation, and R&D testing on E-Motorcycles and E-Scooters
Dynamometer specification
- Roller diameter :215 mm
- Roller length :300 mm
- of rollers :2
- Roller Inertia Total :01 Kgm^2
- Total Roller Weight :300-400kg
- load :400 kg
- speed :130 Km/h
- power(absorbable) :8 HP for steady state testing
- power ( Measurable) :20 HP
- wheelbase :940 mm
- wheelbase :1750 mm
Control Panel with PC based Software
This panel is provided with Computer to control the chassis dynamometer load excitation with necessary graphical software to plot and indicate parameters , set up consists of
- software provided to measure ( RPM , Power and Torque) and perform below test
- Power test
- RPM Vs Torque on wheel test
- Acceleration & De-Acceleration test
- Vehicle cost down Test
- Indian Drive cycle test
- Optional software provided to measure ( RPM , Power and Torque) and perform below test
- Vehicle Load Simulations (Rider, Pillion, Payload etc)
- Road Simulations (flat, uphill, downhill, aerodynamic drag, etc
- Optional : the Below ev two wheeler is provided to test
- Model : Ampere Magnus Neo ( Crompton Make)
- Range : 95-118 km/charge
- Top Speed : 65 kmph
- Motor Power : 1.5 kW
- Max Power : 2.4 kW
- Motor Type : BLDC
- Wheel Size : 12-inch alloy wheels
- Max Loading Capacity: 150 kg
For More Details. Contact : shanmugam@powerlabinstruments.com
