EV Hub.Motor and Controller (PEV-2.0)

EV Hub.Motor and Controller (PEV-2.0)

Category:

Description

Set up consists of

  1. BLDC HUB Motor with spring balance load set up
  2. BLDC Motor controller
  3. Battrey

BLDC Motor (HUB)

Type                :           3 Phase BLDC

Voltage           :           60V or 48V

Power              :           up to  1KW

Speed              :           350RPM

Feedback         :           3 numbers of Hall sensor

Load set up     :           Spring balance Load set up with brake Drum

E vehicle Motor Controller(BLDC Drive)

             This controller used to study & testing of Ev-BLDC motor (hub Type). Commercial motor drive  used in this system to understand the working concept of the BLDC machines by user. it consists of

 Features

  • Meters for drive input dc voltage measurement
  • Digital meters for motor speed Measurement
  • Potentiometer for speed adjustments
  • SPDT switches for Forward /Reverse selection
  • MCB for input DC ON/OFF, Fuse for output side
  • DC Source (Or Battery Lithium)is provided for drive input
  • 60V input , suitable for 1 kw bldc motor
  • All are mounted on a nice powder coated cabinet with front panel sticker

Battery

  • 60V, 20AH /LFP/With smart BMS
  • 5A Charger
