Description
This set up consists of
- 200W PEM Fuel Cell (PEMFC) with Hydrogen and control panel
- Meter set up
Fuel cell specification:
- Number of Cells:20/40
- Rated Power :100 / 200W
- Rated Performance:12V @ 8.3A or 12V@16A
- Reactants :Hydrogen and Air
- Hydrogen Pressure:0.45 – 0.55 Bar
- Humidification:Self-humidified
- Cooling : Air(integrated cooling fan)
- Hydrogen Flow Rate at Max Output:1.3 L/min
- Hydrogen Purity Requirement :≥ 99.995% (dry H2)
- Efficiency of System :40% at 12V
- Over Current Protection
- Over Temperature Protection
Control Panel
- Necessary MS frame to Fix the above Unit with terminations
- Necessary Digital meters is provided to indicate Fuel cell voltage , current etc
- DC DC Converter & with battery 48V, 60V
- Gas with Cylinder : One number of Hydrogen Cylinder filled with Hydrogen Gas with regulator
