Description
Specifications
- Bandwidth : 70MHz
- Channel : 4 CH
- Real-time Sampling Rate: 1GSa/s
- Memory Depth : 64K
- Bandwidth Limit : 20MHz
- Trigger Mode : Edge, Pulse, Video, Alternative
- Trigger Source : CH1, CH2, CH3,CH4
- Waveform Signal Process : +,-,x,÷,FFT, Invert
- Cursors Measurement : Cross, Trace, Horizontal, Vertical
- Auto Measurement : Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase, Vavg, Vrms, Preshoot, Overshoot, Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle
Accessories :
AC/DC Current Probe (3 qty) : Clamp type / AC or DC /frequency range: Up to 20KHz /Effective Measurement Range: 20mA to 65A
Voltage Probe : 1:1 Probe with clip / 20mhz bandwith signals
Mini Computer
Type : X86 Mini PC with 4 Intel Gigabit Ethernet Ports
Processor : Quad Core Celeron N2940, 4GB RAM, 128GB SSD , N2940 Quad Core Quad Threads 1.83-2.2GHZ
GPU : Intel HD Graphics for Intel Processor Z3700 series
Memory (RAM) : DDR3L SO-DIMM Socket 4GB included ( Can Supports upto 8G, 1333MHz)
Storage : 64GB, 1 x Mini-PCIE for mSata
LAN : 4 x Intel 1211-AT-10 / 100 / 1000 Controller
Connectors(F.Panel) : 2 x USB 3.0 port /1 x HDMI/1 x VGA
Connectors(R.Panel) : 1 x DC (DC Jack) &4 x Intel RJ-45 Ports for Gigabit LAN
Supported OS : Support pfsense, Linux Ubuntu, Windows 7/8/10
For More Details Contact : shanmugam@powerlabinstruments.com
