Description
This dc distribution system Trainer is designed to study the various type of dc distribution network system like
- distribution system fed at one end
- distribution system fed at both end
- distribution system fed at centre
- Ring Main distribution system
It consists of
- Two number of Variable dc source ( act as DC Generator source) – is provided for Two wire or three wire – ±12V system simulation
- Provision to connect loads at variable line locations.
- Different types of Load resistor is provided with load selector switch
- Variable Line resistance is provided and selector switch is provided to select line resistance value
- Measurement of voltage and current at any point on the line segments
- Two numbers of Digital Voltmeter is provided
- 10 numbers of digital dc ammeter is provided to measure line current
- All are mounted on a nice cabinet with sticker front panel
- 230V AC input with Power ON/OFF Switch
