Description
This unit is designed to test the di-electric strength of transformer oil ( oil break down test). This set up consists of
Specification
- Type Transformer oil test kit
- Capacity 60KVA Center tap earthed.
- Mode Automatic (Motorized) type /Manual Type
- Input 230VAC
- Make Power Lab
The standard oil cup provided with the set is as per IS 6792 i.e. High Impact Methyle Mathacrylate (Acrylic) test cup along with removable Mushroom Head Electrodes, GO & NO GO gauge to adjust Electrode gap.
- The H.V. Transformer used in the set is a Resin Encapsulated HT Transformer. The Transformer is so designed that the short circuit current of the secondary is more than 20mA at all output voltage above 15KV.
- The stepless voltage regulator is of toroidal autotransformer ensuring maximum efficiency and harmonic free output voltage.
- The set is enclosed in a easy to handle fine industrial finish rugged MS box.
- Clear Plastic Lid through which the oil is observed while testing.
- Panel Lamps are provided to indicate various conditions i.e. “MAINS ON” “H.T. ON”.
