Motor-Generator/Alternator set up (PML-02S)

Category: Machines Lab

Description

DC Shunt/Series/Compound Motor Coupled with Shunt/Series/Compound Generator set/1 -5 hp/220vdc,1500rpm/Make : BENN/RAMSON
DC Shunt /Series/Compound Motor Coupled with Shunt/Series/Compound Generator set/1 -5 hp/220vdc,1500rpm/Identical set/Make : BENN/RAMSON
DC Shunt Motor Coupled with Single Phase Alternator/1 -5 KVA/220vac,1500rpm/Make : BENN/RAMSON
DC Shunt Motor Coupled with 3 Phase Alternator/1 -5 KVA/220vac,1500rpm/Salient or Non Salient Pole/Make : BENN/RAMSON
DC Shunt Motor Coupled with 3 Phase Slip ring Induction Motor/1 -5 hp/220vac,1500rpm/Make : BENN/RAMSON
DC Shunt Motor Coupled with 3 Phase Induction Motor/1 -5 hp/220vac,1500rpm/Make : BENN/RAMSON
DC Shunt Motor Coupled with 3 Phase Synchronous Motor/1 -5 hp/220vac,1500rpm/Make : BENN/RAMSON

Coupled set up

Both Motor and Generator are coupled each other using Tyre coupling with powder coated Mechanical Base plate.
Speed sensor & Sensor Mounting arrangements

M.S. Stand

M.S Stand to fix the Motors ( instead of Civil Bed) with antivibration bush-optional
